Tech-Systems buys, sells and rents hi-tech Test Equipment. We have over 25,000 items in stock and decades of experience in the sales and service of Test Equipment, Lab /R&D and industrial hi-tech equipment. At Tech-Systems we price our gear to sell and stand by all sales with a

7 Day Unconditional Right of Return and a 15 Day Guarantee on all items from receipt of delivery.



Email us today!



LAST UPDATE
8/9/2011

Coming Soon..

Tech-Systems
Lab/R&D Gallery


a

Lindgren ETS Series 81 RF Shielded Room

9' x 7' x 8'

with LRX-2030-S2 EMI/RFI Filter

  • "Hat & Flat" Clamping System for Shield Integrity
  • 28-Gauge Galvanized Steel Panel Lamination
  • Easy to Move - Relocation Service Available
  • Modular Panel Construction
  • Dimensions: 9' x 7' x 8'
  • Included: LRX-2030-S2 EMI/RFI Filter

$11,995

81Room


TA Instruments TMA 2940

Thermomechanical Analyzer

TA Instruments 2940 TMA monitors dimensional changes as a function of temperature. This allows determination of softening points and thermal expansion coefficients from -150C to 1000C. Samples may be run in compression (dilatometry and penetration experiments) or tension (suitable for films and fibres). Modulated-temperature programming is also possible with this instrument.
  • -150° to 1000° C
  • Precision of ±1°C
  • Furnace Air Cooling Time is <10 Min. From 600°C to 50°C
  • Maximun Solid Sample Size 26 mm X 10 mm
  • Maximun Static Opt Sample 26 mm  X 1.0 mm X 4.7 mm
  • For Film or Fiber

$19,995
tma



HP E4433B

250kHz to 4 GHz - Digital RF Signal Generator

w/  Options: 1E5/ UND/ UN4/ UN5/ UN7


  • 250 kHz to 4 GHz Frequency Range
  • RF Modulation Bandwidth Up to 35 MHz
  • Optional Dual Arbitrary Waveform Generator and/or Real-time I/Q Baseband Generator
  • 40 MHz Sample Rate and 14-bit I/Q Resolution
  • 1 Msample (4 MB) Memory for Waveform Playback and 1 Msample (4 MB) Memory for Waveform Storage.
  • Custom Digital Modulation (>15 variations of FSK, MSK, PSK, and QAM), AM, FM, Phase Modulation, Pulse Modulation, and Step/list Sweep
  • E443xB Signal Studio Software Personalities (Bluetooth, 1xEV-DO)
  • E443xB Firmware Personalities(3GPP W-CDMA, cdma2000, IS-95-A, GSM/EDGE)
  • GPIB and RS-232 Connectivity

$8,995




HP 35665A
Dynamic Signal Analyzer

  • Dual Channel FFT Dynamic Signal Analyzer
  • Network, Spectrum, Waveform, Transient Analysis.
  • 8 Traces.
  • 12.8 KHz Real-Time Fast Average.
  • 1.44MB Internal DOS) Floppy Disk Drive.

$3,395
35665a



HP/Agilent 83712B
Synthesized CW Generator

w/ Option: 1E5

Fundamental oscillators and switched low-pass filters deliver <-50 dBc harmonics, eliminate subharmonics and suppress spurious to <-60 dBc. This signal source provides plenty of output power (typically >+14 dBm), while spectral purity is maintained even at high power levels (typical output power at frequencies below 1 GHz is +20 dBm).

  • 83712B: 10 MHz to 20 GHz
  • 1 kHz frequency resolution
  • Level accuracy of +/-1.0 db with 0.01 dB of resolution
  • -50 dBc harmonic distortion
  • Greater than 100 dB of dynamic range
  • Phase noise as low as -103 dBc
 Option 1E5- High Stability Timebase

$11,995





HP/Agilent 53151A
CW Microwave Frequency Counter 26.5GHz

w/ Option 001

The Agilent 53151A is a full-featured 26.5 GHz CW microwave counter and power meter that is perfectly suited for bench top or ATE environments yet is tough enough to handle the most rugged field applications. It offers high performance with an extra-wideband input that covers the RF and microwave spectrum from 50 MHz to 26.5 GHz. Frequency and power are measured simultaneously with this same input.

Option 001 - High Stability Oven Timebase

$7,995



- All items Fully Guaranteed
- Unconditional Right of Return on Every Purchase

OVER 25,000 ITEMS IN STOCK!!!

Tech-Systems Electronics, Inc. has been a global supplier in the Used Test Equipment industry since 1989. We buy and sell all types of test and measurement equipment.
With the largest inventory on the East Coast, you will find what you're
looking for at huge discounts.

Our website features most but not all of our constantly
changing test equipment inventory
.


If you can't find what your looking for, please call, fax, or e-mail us.

Sales@tech-systems.net
1 - 800 - 435 - 1516
Ph: 732-918-7979
Fax: 732-918-7888

Tech-Systems Electronics, Inc.
1750 Brielle Ave., Suite A3 & A4
Ocean Township, NJ 07712

Se habla Español.

Por favor preguntar por Julio,
Compramos y vendemos
